APPLICATION :
2000I & 2000IK is a multi-service packing capable of a wide variety of uses throughout a plant. It is particularly suited for use in high temperature, high pressure steam service. In addition, it can also handle most chemicals, acids and alkalis. Style 1102 and 1103 is excellent for use in steam turbines, high temperature motor-actuated valves and for high temperature and high pressure valve applications in general.
Precaution: in oxidizing environment.
Recommendation: May use with Aimlon 1203 high carbon fiber anti-extrusion packing rings.
SERVICE LIMITS:
|
|
Valves |
Agitators |
|
Pressure |
400Bar |
50Bar |
|
Shaft speed |
2m/s |
2m/s |
|
Density |
1.1~1.4g/cm3 (+5% for 2000K) |
|
Temperature |
-220~+5000C(+5500C with steam) |
|
PH range |
0~14 |
FORMS OF SUPPLY:
in coils of 2 to 5 kg, other package on request.
as packing rings---R1102,R1103 etc.
as precut length
|
