PROPERTIES & APPLICATION:
|
Item |
Style |
|
2900 |
2901 |
2902 |
2903 |
|
Tensile strength >=Mpa |
9 |
11 |
12.7 |
13 |
|
Compressibility>=% |
7~17 |
|
Recovery>=% |
35 |
45 |
50 |
50 |
|
Density g/cm3 |
1.6~2.0 |
|
Tmax: oC |
150 |
250 |
300 |
400 |
|
Pmax: Mpa |
1.5 |
2.5 |
3.0 |
4.0 |
|
At 20# air lub oil,15~30 oC for 30min |
Tensile strength>=Mpa |
8 |
9 |
10.8 |
26 |
|
Oil absorption <= % |
23 |
23 |
23 |
9 |
|
Thickness increase% |
|
20 |
15 |
15 |
|
At 75# gasoline /3# 15~30oC
for 5h |
Tensile strength >=Mpa |
6 |
7 |
7.9 |
14.7 |
|
Oil absorption <= % |
22 |
22 |
22 |
15 |
|
Thickness increase% |
|
25 |
25 |
20 |
|
Oil sealing Mpa |
8 |
10 |
15 |
12 |
|
Resistance to media |
Oils, refrigerators, solvents etc. |
Special grade 2910 on request (500 oC, 10Mpa)
Available colour: Green, blue, white etc.
Available with tin steel, SS304 etc. wire mesh insertion(29**I)
Also available with anti-stick (29**S) or graphite coating (29**G)
FORMS OF SUPPLY:
Sheets
1500x4000mm, 1500x2000mm
1500x1350mm, 1500x1000mm
1270x3810mm, 1270x1270mm
Thickness: 0.4~6mm
Cut gaskets
G2900~G2903 Dimensions according to drawings or and standards. |
