Benefits

Tight seal

• Perforated stainless steel core increases resistance to pressure fluctuations and thermal cycling
• GYLON® offers superior cold flow and creep resistance, eliminating the need for frequent retorquing
• Excellent replacement for metal-inserted envelope gaskets, PTFE-filled spiral wounds and wireinserted asbestos gaskets in many applications

Chemical resistance

• Seals aggressive chemicals in hostile environments where safety or blowout resistance is crucial

Media

• Strong acids (except hydrofluoric)
• Solvents
• Hydrocarbons
• Water
• Steam
• Chlorine
• Cryogenics (For oxygen service, specify "HP3562 for oxygen service.")


  Specifications

  Min. Temperature: -450 (° F) Max. Temperature: 500 (° F) Max. Pressure: 2500 (PSI) Maximum PxT 1/16: 700000 (° F x PSIG) Maximum PxT 1/8 : 450000 (° F x PSIG)
