Carbonized Fiber Packing
Carbonized Fiber Packing
Braided from shrink-proof synthetic fiber impregnated with PTFE dispersion containing graphite particles, silicon-oil-free, which is oxidized polyacrylonitrile fiber. Compared to traditional carbon fiber packing, it is not brittle, can suited for high peripheral speeds.
Oxidized fiber has high strength and good thermal conductivity,  PTFE and graphite makes the packing have excellent self-lubrication, so this packing does not damage shafts and has long life.

2100I Carbonized Fiber Packing Reinforced with Nickel wire

The wire reinforcement provides increased mechanical strength, usually for static.
APPLICATION:
It can be used in weak acids and alkalis or media containing few grains of solid particles, both dynamic and static, mainly used for centrifugal pumps, plunger pumps, mixers and valves.
Without cooling it can be used with hot water up to 160¡ãC , with cooling it can be used with hot water up to 207¡ãC. Particularly ideal for hot water, condensate and main coolant pumps.
SERVICE LIMITS:
Temperature
-50~+280 ¡ãC
Pressure-Shaft
Rotating
20 bar-25m/s
Reciprocating
100 bar-2m/s
Valve
200 bar-2m/s
PH Range
2~12
Density(appr.)
1.1~1.3g/cm3

FORMS OF SUPPLY:
in coils of 1 to 5 kg, other package on request.
as prepressed rings----R2100, R2100I
as precut length
STOCK DIMENSIONS:

Size mm
8
10
12
12.7
14
16
appr. m/kg
11.5
7.4
5.0
4.46
3.7
2.8
Appr. ft/lb
17.1
11.0
7.4
6.6
5.5
4.2
kg/coil
2
5

Weight of 2100I:  approx 10% greater than 2100.
