 Ceramic Fiber PackingASSEALS 2700
Braided Ceramic fiber packing
ASSEALS 2700I
Ceramic fiber packing reinforced with Nickel/SS wire
ASSEALS 2700G
Ceramic fiber packing with graphite impregnation
ASSEALS 2700IG
Graphited ceramic fiber packing reinforced with nickel wire
ASSEALS 2702
Twisted braided ceramic fiber rope
ASSEALS 2704
Round braided ceramic fiber rope
ASSEALS 2706
Braided ceramic fiber lagging rope
APPLICATION:
As a static seal for vessels, heaters, manhole, lids, covers etc. Suited for chemically neutral and resistant to water, steam, hot air, oils and so on.
Round, square and rectangular sections on request.
Reinforcement material, nickel/SS wire and glass fiber and other are also available.
Size:5~60mm 25m/roll
T:650°C With fiberglass
T:100°C With Nickel
Dimensions:
|
SQUARE BRAIDED PACKING |
|
SQUARE SIZE |
ROLL |
WEIGHT |
|
mm |
MTR |
GR./MTR |
|
5 x 5 |
200 |
18 |
|
6 x 6 |
100 |
25 |
|
8 x 8 |
100 |
45 |
|
10 x 10 |
50 |
65 |
|
12 x 12 |
50 |
90 |
|
14 x 14 |
50 |
130 |
|
15 x 15 |
50 |
150 |
|
16 x 16 |
50 |
170 |
|
18 x 18 |
50 |
190 |
|
20 x 20 |
50 |
240 |
|
22 x 22 |
30 |
290 |
|
25 x 25 |
30 |
380 |
|
28 x 28 |
30 |
470 |
|
30 x 30 |
20 |
540 |
|
35 x 35 |
20 |
740 |
|
40 x 40 |
10 |
880 |
|
50 x 50 |
10 |
1380 |
|
60 x 60 |
10 |
1980 |
Above data only for your reference |
