Graphite Sheets
Graphite Sheets
ASSSEALS 4000 Pure Expanded graphite sheets & rolls (4000L) are selected from the high purity natural flake graphite. They are made through the advanced chemical treatment and mechanical procedure without fibers, binders or other additives. It offer excellent sealing capabilities under extreme conditions with a longer life and less maintenance.
                     Nuclear Style grade:4000/N,4000L/N

APPLICATION :            Made for packing rings and various kinds of gaskets.
                                         Used widely in chemical, automotive and pump, valve industries.
                                         As a superior replacement for asbestos, new more applications are
                                         Being identified daily.


LIMITS OF

APPLICATION :            Temperature:   -240~500°C under oxidizing environment
                                                                         -240~3500°C under non-oxidizing environment
       PH Range:     0 - 14


PROPRTIES:

Item
Sheets
Rolls
Density  g/cm3
1.0
1.0
Length
1000, 1500mm
30~100m
Width mm
1000, 1500
1000~1500
Thickness mm
0.5~3
0.2~1.1








Item
Nuclear
grade
Industrial grade
Tolerance of Density   g/cm3
±0.05
±0.06
Carbon Content       ≥%
99.5
98
Tensile strength       ≥Mpa
5
4
Compressibility       ≥%
30
30
Recovery             ≥%
15
15
Sulphur Content       ≤%
700
1200
Chlorine Content      ≤%
25
50
Stress relaxation rate  %
10
10
Lgnition loss          ≤%
0.5
2.0
>







Special density, thickness, shape or grade available on request.
Style of graphite cut gasket:G4000

CONSTRUCTION:       Gasket sheet 4002, made of expanded flexible graphite 4000,
reinforced by a smooth stainless steel-carrier of 1.4301 (304) or 1.4401 (316), Nickel, 0.05mm thick, graphite content of more then 98 %, graphite bulk density 1.0 g/cm3.
Normal  Style: 4002/304
                        4002/316
                              4002/Other metal foil material

APPLICATION :            Made for various gaskets.
Suitable for Petrochemical, Mining, Vessels, Boilers, Piping and Duct, Pumps and Valves, Flanges,



LIMITS OF

APPLICATION :            Temperature:          -200... up to 550°C

                                         Pressure:         ..up to 200 bar

PH Range:         0 - 14


PROPERTIES  :          Permanently elastic, even in hot-cold cycles over the entire temperature range, no aging, no brittleness, no hot or cold flow, long time uniform compressibility and resiliency independent of temperature.

RESISTANCE
TO MEDIA    :             steam, mineral oils, heat transfer oils, hydraulic oil, fuel, water, seawater, freshwater etc.

Forms of supply:    Sheets
  Gasket: G4002
  Gasket with inner eyelet
  G4002-IE
  Gasket with inner & outer eyelets
  G4002-IOE

Standsrd dimension:
1000 x 1000 x 1.0 ; 1.5 ; 2.0 ; 3.0mm
1500 x 1500 x1.0 ; 1.5 ; 2.0 ; 3.0mm

Gaskets cut to size (full or segment)
Special density, thickness or insert materials available on request.
CONSTRUCTION:       Gasket sheet 4004, made of expanded flexible graphite 4000, reinforced by a tanged (perforated) stainless steel-carrier of 1.4301 (304) or 1.4401(316), 0,1mm thick, graphite content of more then 98 %, graphite bulk density 1.0 g/cm3.
Normal Style: 4004/304
4004/316
4004/CS (Carbon steel)
4004/Other tanged metal material

APPLICATION :            Made for various gaskets.
Suitable for Petrochemical, Mining, Vessels, Boilers, Piping and Ducting, Pumps and Valves, Flanges,


LIMITS OF
APPLICATION :            Temperature:          -200... up to 550°C

                                          Pressure:         up to 500 bar

                                          PH Range:        0 - 14


PROPERTIES  :          Permanently elastic, even in hot-cold cycles over the entire temperature range, no aging, no brittleness, no hot or cold flow, long time uniform compressibility and resiliency independent of temperature.

RESISTANCE
TO MEDIA :                    steam, mineral oils, heat transfer oils, hydraulic oil, fuel, water, seawater, freshwater etc.


Forms of supply:    Sheets
                                         Gasket: G4004
                                         Gasket with inner eyeletting:
                                          G4004-IE
                                         Gasket with inner & outer eyeletting
                                          G4004-IOE

Standsrd dimension:1000 x 1000 x 1.0 ; 1.5 ; 2.0 ; 3.0mm
1500 x 1500 x1.0 ; 1.5 ; 2.0 ; 3.0mm
                    Gaskets cut to size (full or segment)
                    Special density, thickness or insert materials available on request.

CONSTRUCTION:       Gasket sheet 4006, made of expanded flexible graphite 4000, reinforced by a metal mesh of 1.4301 (304) or 1.4401(316) or CS (Carbon steel), graphite content of more then 98 %, graphite bulk density 1.0 g/cm3.
                                          Normal Style: 4006/304

4006/316

4006/CS (Carbon steel)
4006/Other metal mesh


APPLICATION :            Made for various gaskets.
Suitable for Petrochemical, Mining, Vessels, Boilers, Piping and Ducting, Pumps and Valves, Flanges,


LIMITS OF
APPLICATION:             Temperature:         -200... up to 550°C

                                          Pressure:         up to 500 bar

                                          PH Range:        0 - 14


PROPERTIES  :          Permanently elastic, even in hot-cold cycles over the entire temperature range, no aging, no brittleness, no hot or cold flow, long time uniform compressibility and resiliency independent of temperature.

RESISTANCE
TO MEDIA    :             steam, mineral oils, heat transfer oils, hydraulic oil, fuel, water, seawater, freshwater etc.

Forms of supply:    Sheets
                                         Gasket: G4006
                                         Gasket with inner eye-letts:
                                          G 4006/G-IE
                                         Gasket with inner & outer eye-letting
                                          G 4006/G-IOE

Standsrd dimension:1000 x 1000 x 1.0 ; 1.5 ; 2.0 ; 3.0mm
1500 x 1500 x1.0 ; 1.5 ; 2.0 ; 3.0mm
                    Gaskets cut to size (full or segment)
                    Special density, thickness or insert materials available on request.
