Non-asbestos sheets
Non-asbestos sheets
CONSTRUCTION:

Asseals Non-asbestos sheet is made from synthetic fibre, natural rubber, filling material and dye, compressed and calendered under high temperature and pressure into a sheet form. It eliminates asbestos-rubber sheet essentially and thoroughly.

PROPERTIES & APPLICATION:

Item
Style
 4100
 4102
 4104
Density
g/cm3
1.8~2.0
1.8~2.0
1.8~2.0
Tensile strength≥Mpa
6
9
12.5
Compressibility
≥%
12±5
12±5
12±5
Recovery
≥%
40
45
45
Aging
coefficient
0.9
0.9
0.9
Stress relaxation ≤%
45
45
45
Steam Sealing
Tmax: 200℃
Pmax: 2~3Mpa
30min
no shock
Tmax: 300℃
Pmax: 4~5Mpa
30min
no shock
Tmax: 400℃
Pmax: 8~9Mpa
30min
no shock
Tmax:  ℃
200
300
400
Pmax:  Mpa
1.5
3.0
5.0
Resistance
to media
Water, seawater, steam, fuel, gases, salt solutions and many other media.

Normal colour: Black with some white, Red or Green-white
Available with tin steel, copper, SS304 etc. wire mesh insertion (41**I)
Also available with anti-stick(41**S)or graphite coating (41**G)
FORMS OF SUPPLY:
Sheets:        Thickness:  0.5~5mm
2000×1500mm; 2000×4000mm;1500×1500mm;
1500×1000mm;1270×1270mm; 3810×1270mm
Cut gaskets    G4100/2/4
Dimensions according to drawings or and standards

CONSTRUCTION:

Asseals oil-resisting non-asbestos sheet is made from Kevla fibre, synthetic rubber, filling material and dye, compressed and calendered under high temperature and pressure into a sheet form. It eliminates asbestos-rubber sheet essentially and thoroughly.

PROPERTIES & APPLICATION:

Item
Style
4110
4112
4114
Density
g/cm3
1.7~1.9
1.7~1.9
1.7~1.9
Tensile strength
≥Mpa
8
11
12
Compressibility
≥%
12±5
12±5
12±5
Recovery
≥%
45
50
50
Stress relaxation ≤%
45
45
45
20# aviation lub oil for 150℃*5h
Thickness increase ≤
18
15
15
Weight increase≤
20
16
16
ASTM No.3#-5H 150℃
Thickness increase ≤
20
20
20
Weight increase≤
18
14
14
Tmax:  ℃
200
300
350
Pmax:  Mpa
2.0
3.0
3.5
Resistance
to media
Oil fuel, gases, salt solutions and many other media.

Available colour: Black with some white, Red or Green-white, etc.
Available with tin steel, copper, SS304 etc. wire mesh insertion (411*I)
                                    Also available with anti-stick (411*S) or graphite coating (411*G)
FORMS OF SUPPLY:
Sheets:        Thickness:  0.5~5mm
2000×1500mm; 2000×4000mm;1500×1500mm;
1500×1000mm;1270×1270mm; 3810×1270mm
Cut gaskets    G4110/2/4
Dimensions according to drawings or and standards

CONSTRUCTION:
                                  Asseals GS4120 Non-asbestos expanded & wet sealing type sheet is made from synthetic emulsion, plants fiber and filling material. The production is used for position of lubrication system, which has the property of good compressibility and coefficient of resilience, in addition, the inside of gasket can properly swell to meet oil, that make up of the shortcoming that procession machining precision is not enough, which affected self-sealing.

PROPERTIES & APPLICATION:

Item
Style
GS 4120/W
GS 4120/O
Density          g/cm3
1.20~1.40
1.20~1.50
Tensile strength   ≥Mpa
12.7
12.7
Compressibility ≥%
20±5
15±5
Recovery      ≥%
45
45
Stress relaxation ≤%
35
30
In 20# aviation oil,
150℃, 30min
Oil absorption

≤35%
Thickness increase

≤15%
In 10# motor oil,
150℃, 5h
Thickness increase
≥15%

In water
15~30℃, 5h
Thickness increase
≥30%

Application
Applicable to sealing to water coolant of explosion diesel engine and the articulation of canal flange of water supply system
Applicable to sealing petrel, diesel oil, mixed oil and chemical canal

Normal colour: Black, Grey
Available with tin steel, copper, SS304 etc. wire mesh insertion
                                    Also available with anti-stick or graphite coating
FORMS OF SUPPLY:

Sheets

Width:      1040mm;     Length:     1150mm
Thickness:  0.3~2.0mm


Cut gaskets ---4120/G

Dimensions according to drawings or specifications and standards

CONSTRUCTION:

Asseals 4120DI Double-face tanged CS+NCAF
It is made of Aiflon 4120 non-asbestos Beater sheet reinforced with single-tanged 0.2-0.25mm Carbon Steel on double-face.

Asseals 3000DI Double-face tanged CS+CAF
It is a composite from Aiflon 3000 Asbestos beater sheet reinforced with single-tanged 0.2-0.25mm carbon steel on double-face

APPLICATION:

It is extensively applied in manufacturing various exhaust gaskets for automobile and motorcycle etc.



FORMS OF SUPPLY:

Sheets

Size: 500×1000mm; 500×500mm
Thickness:  1.2~2.5mm
Packing:
in strong export standard cases of about 1000 kgs net each


Cut gaskets

G4120DI, G3000DI
Dimensions according to drawings or specifications and standards.

CONSTRUCTION:

Asseals GS4120I is made of 4120 Non-asbestos gasket sheet reinforced with tanged 0.2-0.25mm Carbon Steel. It is extensively applied in manufacturing various motor gaskets. It is a new material that will substitute asbestos products. The product has excellent performance in dilatability, sealing equality and long life etc., Mainly applied in automobile farming machine, motorcycle and engineering etc., it is also can be used in high strength gaskets and cylinder gaskets etc.

Aiflon GS3000I is made of 3000 asbestos emulsion sheet reinforced with tanged 0.2-0.25mm Carbon Steel

PROPERTIES & APPLICATION:

Item
Style
GS 4120I, GS 3000I
Density          g/cm3
1.30~1.50
Tensile strength   ≥Mpa
12.7
Compressibility ≥%
10±5
Recovery      ≥%
40
Sealing performance
<0.5cm3/min
Performance of heat-resistance
150-300℃

Normal colour: Black, Gray, Graphite etc.
Available with SS304. wire mesh insertion
Also available with anti-stick silicon resin---4120IS, 3000IS
or graphite coating---4120IG, 3000IG

FORMS OF SUPPLY:

Sheets

500×1000mm; 500×1200mm; 500×1500mm;
510×1016mm; 510×1530mm;
1000×1000mm ;1000×1500mm;
Thickness:  1.0~2.4mm
Packing:
in strong export standard cases of about 1000 kgs net each


Cut gaskets ---G4120I, G3000I

Dimensions according to drawings or specifications and standards.
