Mica Sheets
Mica Sheets
Asseals 4300 Soft Golden Mica Sheet
Asseals 4320 Soft White Mica Sheet
An asbestos-free sealing material, It¡¯s made by selected mica material mixed with proper adhesive after pressed and baked, It has good mechanical strength and strength and property of heat resistance. It can be cut into various gaskets, also used as filler for spiral wound gaskets. On request, it can be reinforced with tanged metal. It has proven beyond doubt the best and most reliable permanent sealing characteristics, low minimum compressive load, self-adjusting to enlarging gaps, no burning or sticking to flanges, compensating action in ceramic/steel joints with unequal expansion.

4300I Golden Mica Sheet Reinforced with Tanged Metal (1.2~5mm)
Normal reinforcement materials: Tanged carbon steel, SS304, SS316 etc

Normal Size mm
1000×1200, 600×1000
Thickness
0.5~5mm
Temperature
650~900°C
Pressure
10Mpa
Density
1.8~2.1g/cm3







Insulation Materials:

4322 Hard White/Golden Mica Sheet
High-performance thermal and electrical insulation is designed for electromechanical and thermomechanical applications requirement, It is used as a replacement for asbestos and other insulating boards for a variety of applications.

Item
Test by
4322
Binder content %

10-15
Density g/cm3
IEC371-2
2.45
Heat Resistance
Continuous°C

500/700
Peak°C

700/1000
Weight loss continuous temperature
500°C %

<1
700°C %

<2
Water absorption 24h/23°C %

<1
Fire resistance classification
UL94
94V-0
Dielectric strength
20°C kV/mm
IEC243
25
400°C/ 1 hour, tested at 20°C kV/mm
IEC243
13
600°C/ 1 hour, tested at 20°C kV/mm
IEC243
10
Volume resistivity
20°C ohm.cm
IEC93
10-16
400°C ohm.cm

10-12
500°C ohm.cm

10-9
Normal dimension: 1200×1000mm, 600×1000mm, Thickness: 0.2~80mm

Note: UL Recognized Component 94V-0 Flame Class Rating, File card E216697
