Ceramic Blanket
Ceramic Blanket
ASSEALS Ceramic Blanket
Specification and properties of ceramic fiber blanket
Type/ Item
 STD
 HP
 HA
ZR
Colour
White
Dia. of fiber (μm)
2~4
2~4
2~4
2~4
Thickness(mm)
6~50
6~50
10~50
10~50
Regular size(mm)
7200×600×25 and 3600×600×50
Working temp.(℃)
1050
1100
1200
1350
Max. temp.(℃)
1260
1260
1350
1450
±10%
Bulk density
(kg/m3)
64,96,128,160,192
96,128,160,192,224
(pcf)
4,6,8,10,12
6,8,10,12,14
Thermal shrinkage for 24hrs(%)
1150℃
≤3
1250℃
≤3.5
1300℃
≤3.5
1350℃
≤3.5
Thermal conductivity (W/m.k)
128 kg/m3
or 8 pcf
800℃ 0.15
800℃ 0.15
1000℃ 0.18
1000℃ 0.23
1000℃ 0.17
1000℃ 0.18
1200℃ 0.26
1200℃ 0.31
160 kg/m3
or 10pcf
800℃ 0.14
800℃ 0.13
1000℃ 0.17
1000℃ 0.21
1000℃ 0.16
1000℃ 0.17
1200℃ 0.24
1200℃ 0.30
Al2O3(%)
45~47
47~49
53~55
38~54
Al2O3+SiO2(%)
98.5
98.5
99
82~90
ZrO2(%)
-
-
-
10~18
Fe2O3(%)
<0.4
<0.3
<0.2
<0.2
K2O+Na2O(%)
<0.3
<0.3
<0.2
<0.2
CaO+MgO(%)
<0.2
<0.2
<0.2
<0.2
DESCRIPTIONS:
Asseals 4402 Ceramic fiber board is produced from corresponding blowing fiber with vacuum formed technology. Ceramic fiber boards not only possess the typical function of ceramic fiber, but also have hard texture, excellent toughness and intensity, and excellent fire resistance and heat preservation. They feature low thermal conductivity and low heat storage, excellent thermal stability and thermal shock resistance, and outstanding acoustic insulation.
SPECIFICATIONS:


Type
4402
Colour
White
Dia. Of fiber(μm)
3~5
Length(mm)
600~1200±10
Width(mm)
400~600±10
Thickness(mm)
10~80±4
Density(kg/m3)
140~360±15%
Working temp.(℃)
1000
Max. temp.(℃)
1260
Linear shrinkage for 24hrs
≤4%(900~1000℃

Other specifications are available on request,Style HP,HA,ZR is for high temperature
APPLICATIONS:
▲Insulation material of back lining in the field of cement and architecture
▲Insulation material of back lining in the industry of colored metal
▲Insulation material of heat-dealing furnace
▲Insulation material of back lining in the field of metallurgy and petrochemical
▲Insulation material of back lining of high temperature and heating equipment

ADVANTAGES:
★Excellent compressive strength and excellent toughness
★Excellent thermal stability and thermal shock resistance
★Excellent machine-processed capability
★Low thermal conductivity
★Low heat storage
★Excellent resisting wind capability

ORDER SAMPLE:

Style:4402 Ceramic fiber board
Denstiy:300kg/m3
Size:900×400×40mm
