ASSEALS 2400 Ramie Fiber Packing with PTFE
Highest quality ramie fiber impregnated with light-colored, special PTFE and inert lubricant during square plaiting operation. It can prevent product contaminated. Low maintenance, easy-to-control, it is not harsh on shafts and stems.
2400SC Ramie packing with silicon Rubber Core
High elastic silicon core can absorb vibration, to control leakage.
ASSEALS 2400G Ramie Packing with graphite & oil impregnation
Square braided construction, graphite coated and mineral oil lubricated throughout.
APPLICATION:
|
Style |
Application |
|
2400(SC) |
For pumps, refiners, filters and valves in the brewing and beverage industry, shipbuilding and other fields. Especially resistant to abrasive media in the paper industry. |
|
2400G |
A medium hard packing which is lubricated and graphited throughout. Extremely low frictional characteristics where minimum shaft wear is essential. Rot resistant and ideal for marine use, handling cold water, brine and cold oils. |
SERVICE LIMITS:
|
Style |
2400(SC) |
2400G |
|
Density |
1.25g/cm3 |
1.25g/cm3 |
|
PH range |
5~11 |
6~8 |
|
Maximum Temperature °C |
130 |
100 |
|
Pressure bar |
Rotating |
20 |
15 |
|
Reciprocating |
20 |
15 |
|
Static |
30 |
20 |
|
Shaft speed |
m/s |
10 |
6 |
FORMS OF SUPPLY:
in coils of 2 to 5 kg, other package on request.
as prepressed rings----R2400(SC), R2400G
as precut length
STOCK DIMENSIONS:
|
Size mm |
5 |
6 |
8 |
10 |
12 |
13 |
14 |
15 |
16 |
18 |
20 |
22 |
25 |
|
appr. m/kg |
33 |
23 |
13 |
8.0 |
5.5 |
5.0 |
4.2 |
3.7 |
3.2 |
2.5 |
2.1 |
1.7 |
1.3 |
|
Appr. ft/lb |
49 |
34 |
19 |
12 |
8.2 |
7.4 |
6.2 |
5.5 |
4.8 |
3.7 |
3.1 |
2.5 |
1.9 |
|
kg/coil |
2 |
5 |
ASSEALS 2440 Cotton Fiber Packing with grease
Pre-impregnated, twisted cotton yarns, intensively re-impregnated during braiding. Flexible and elastic, easy to handle. It¡¯s an economical packing for the limits of application stated.
2440W is white,2440Y is yellow.
ASSEALS 2440G Cotton Packing with Graphite & oil
Pre-impregnated cotton yarns treated with graphite, then thoroughly re-impregnated during braiding. The packing is resilient and flexible.
ASSEALS 2440P Cotton Packing with PTFE Impregnation
Made of long cotton fiber yarn impregnated with PTFE and additives. The packing has a low coefficient of friction & is resilient and flexible.(PH:4~10)
APPLICATION:
|
Style |
Application |
|
2440(W/Y) |
An economical universal packing, suitable for rotating and reciprocating pumps, valves, agitators etc with water, sea-water, alcohol, etc. |
|
2440G/P |
Universal packing, for Rotary, reciprocating pumps, in ship building and domestic fresh water pumps.
Style 2440P is designed for hydraulic applications in low and medium pressure pumps and valves, and where contamination is not permitted. |
SERVICE LIMITS:
|
Style |
2440(W/Y) |
2440G/P |
|
Density |
1.25g/cm3 |
1.25g/cm3 |
|
PH range |
6~8 |
6~8 |
|
Maximum Temperature °C |
100 |
130 |
|
Pressure bar |
Rotating |
10 |
10 |
|
Reciprocating |
20 |
20 |
|
Static |
60 |
70 |
|
Shaft speed |
m/s |
10 |
10 |
FORMS OF SUPPLY:
in coils of 2 to 5 kg, other package on request.
as prepressed rings----R2440(W/Y), R2440G/P
as precut length
STOCK DIMENSIONS:
|
Size mm |
5 |
6 |
8 |
10 |
12 |
13 |
14 |
15 |
16 |
18 |
20 |
22 |
25 |
|
appr. m/kg |
33 |
23 |
13 |
8.0 |
5.5 |
5.0 |
4.2 |
3.7 |
3.2 |
2.5 |
2.1 |
1.7 |
1.3 |
|
Appr. ft/lb |
49 |
34 |
19 |
12 |
8.2 |
7.4 |
6.2 |
5.5 |
4.8 |
3.7 |
3.1 |
2.5 |
1.9 |
|
kg/coil |
2 |
5 |
|
