Mineral Fiber Packing

Mineral Fiber Packing
PA 2500 Arcylic Fiber Packing with PTFE

Braided from high strength arcylic synthetic fiber pre-impregnated with PTFE, and re-impregnated during square braiding. It has excellent properties of sealing, lubricating and resistance to chemicals.
2500G is acrylic fiber packing with oil and few PTFE
2500SC is Arcrylic fiber packing with silicon core


PA 2500G Arcylic Fiber Packing Treated with Graphite

Braided of high strength Arcylic synthetic fiber, treated with graphite.
The packing is then re-impregnated during braiding consisting of graphite mixed with special lubrications. Much of graphite filler increases the service temperature and the density of the packing.
APPLICATION:

Style
Application
2500
Excellent multi-service for a wide variety of uses throughout a plant. Used in pumps and valves, and can handle   most chemicals except strong acid, strong alkali and strong oxidizer. Especially for the condition of middle-temperature, high-pressure, high-speed, and where contamination is not permitted.
2500G
Universal packing for pumps and valves, and handle water, air, steam, mild acids and alkalis, all kinds of organic solvents and Chemicals. Especially suitable for the condition of high-temperature, high-pressure, medium-speed.

SERVICE LIMITS:

2500
2500G
T
260°C
350°C
PH
1~13
1~13
V
20m/s
15m/s
Rotating
20bar
25bar
Reciprocating
80bar
100bar
Valve
100bar
150bar
D(g/cm3)
1.1~1.3
1.1~1.3

FORMS OF SUPPLY:

                                      in coils of 2 to 5 kg, other package on request.
as prepressed rings----R2500, R2500G
                                      as precut length

STOCK DIMENSIONS:

Size mm
5
6
8
10
12
13
14
15
16
18
20
22
25
appr. m/kg
33
23
13
8.0
5.5
5.0
4.2
3.7
3.2
2.5
2.1
1.7
1.3
Appr. ft/lb
49
34
19
12
8.2
7.4
6.2
5.5
4.8
3.7
3.1
2.5
1.9
kg/coil
2
5


2540 Kynol Fiber Packing`


Braided from high-performance Kynol (also named novoloid or phenolic) fiber impregnated with special PTFE lubricant, it has very good mechanical properties combining softness and strength. The packing has natural golden sheen. Compared to ordinary aramid and PTFE, it has more benefits as follows:

★    Thermal stability, low heat expansion;
★    High dimensional stability and superior pressure resistance even at elevated temperature;
★              Good process-ability, easy to cut and fit;
★              Outstanding chemical resistance particularly in acidic media;
★              Excellent resistance to organic solvents, oil and fuel...

APPLICATION:

A high performance packing that is well suited to applications where graphite impregnation may not be acceptable. Suitable for abrasive media, and where contamination is not permitted. It has multiple uses in chemical plants and pulp and paper mills, and is regularly used in rotating and reciprocating pumps, washer journals, liquor pumps, refiners and digesters.

SERVICE LIMITS:


Rotating
Reciprocating
Static
Pressure
20 bar
100 bar
200 bar
Shaft speed
20 m/s
1.5 m/s
2 m/s
Temperature
-200~+260°C
PH range
1~13
Density
appr 1.5g/cm3


COMPARISON CHART:

Aiflon
Chesterton
Latty
Teadit
Utex
Speco
Jeil
2540
1727
7188
2777
248
2250
3078

STOCK DIMENSIONS:

Size mm
6
8
10
12
12.7
14
15
16
18
20
22
appr. m/kg
17.7
10.3
6.5
4.5
4.0
3.3
2.9
2.5
1.9
1.6
1.3
Appr. ft/lb
26.4
15.3
9.7
6.6
5.9
4.8
4.3
3.7
2.9
2.4
1.9
kg/coil
5(10 lb/roll)

Glass fiber is standout among the different organic and inorganic fibers as ideal replacement of asbestos. All of Aiflon glass products are made of good quality E-glass fiber, it has many excellent capabilities of high strength and high temperature resistance, low density and low thermal conductivity, better insulation and incombustible etc.

2600 Glass fiber packing

Braided from E-glass fibers without any impregnation, untreated, will not shrink or swell in service. May be ordered square or with a rectangular cross section.
It can be reinforced by nickel wire, stainless steel etc. on request----Style 2600I
2600G Glass fiber packing with graphite impregnation
Square braided from E-glass fiber impregnated with graphite. It also can be reinforced by nickel wire etc. on request------Style 2600IG

2600P Glass fiber packing with PTFE impregnation

Square braided from E-glass fiber impregnated with PTFE, that largely prevents solids from entering the seal and maintains its elasticity.

2602 Twisted Glass fiber rope

A dry, flexible rope.

2604 Round braided Glass fiber rope

Stronger and more stable, also can be reinforced by nickel wire and so on-----Style 2604I
2606 Braided Glass fiber lagging rope
APPLICATION:
As a static seal for vessels, heaters, manhole, lids, covers, thermal insulation and fire-proof of pipes etc. Suited for chemically neutral and resistant to water, steam, hot air, oils and so on.

SERVICE LIMITS
Temperature :         up to 550 °C
                                       (280°C for style 2600P)
PH range:            5~9

FORMS OF SUPPLY:
In coils of 3 ~ 10 kg,
other weight on request

STOCK DIMENSIONS:

Size mm
6
8
10
12
16
20
25
30
32
35
appr.g/m
45
90
120
158
238
325
476
770
833
1000
appr.m/kg
22.2
11.2
8.3
6.3
4.2
3.0
2.1
1.3
1.2
1.0
kg/coil
3
10
Above sheet for 2600,  2600G: appr. +15%;  2600P: appr. +30% in weight.
